Digital Theodolite Topcon DT-309 / DT-309G | No Laser
Harga
Rp43.000.000,-
Tersedia
Brand new design with laser pointer for efficient alignment setting work!
Lightweight, compact angular measurement with highprecision laser guidance and up to 30 workdays of power
• Long-lasting Li-ion or AA battery life with up to 30 workdays*2
of power
• Convenient high-precision laser guidance
• Brand new product design utilizing Topcon premium quality
total station components
• Embedded tilt sensor in 5” model
• Ultra-rugged IP66 dust and heavy rain protection
The DT-300 is a lightweight compact alignment and angular measurement device which uniquely boasts up to 30 working days of power, the highest waterproof and dust protection, and convenient high precision laser guidance.
Features include
High-accuracy (5”, 7” and 9” models) measurements
Ultra-rugged IP66 dust and heavy rain protection
Compact and light weight
Long-lasting Li-ion or AA battery life
Easy-to-use LCD backlit display
Precise laser pointer guidance
Embedded tilt sensor for 5” and 7” models
Speksifikasi Digital Theodolite Topcon DT-309/309G
Telescope
* Length :
- 149mm
- 152mm (L models)
* Aperture : 45mm
* Magnification : 30X
* Image : Erect
* Field of view : 1°30’ (26m/1,000m )
* Resolving power : 2.5"
* Minimum focus
- 0.9m
- 1.0m(L)
* Stadia ratio : 100
* Stadia constant : 0
Angle measurement
* Method : Rotary absolute encoder
* Detecting :
- Horizontal: 1 sides
- Vertical: 1 sides
* Minimum Reading
- 5" Model: 1" (0.0002 gon/0.01 mil)/5" (0.001 gon/0.1mil) (selectable)
- 7" Model: 5" (0.002 gon/0.05 mil)/10" (0.005 gon/0.1mil) (selectable)
- 9" Model: 10" (0.002 gon/0.05 mil)/20" (0.005 gon/0.1mil) (selectable)
Display
* Unit
- 2 sides for 5” and 7” model
- 1 side for 9” model
Tilt angle compensation (5” and 7”models)
* Type : Automatic vertical compensator
* Range of compensation : ±3' (±0.0555 gon)
* Compensation constant : Can be changed (compensation is done at the same time with vertical angle 0 point)
Optical plummet
* Magnification : 3X
* Minimum focus : 0.5 m
Sensitivity of levels
* Circular level : 10’ /2mm
* Plate level : 30"/ 2mm
Power Supply
* Power source : 4 AA dry cells or BDC71 (Optional accessory)
Operating Time (4 AA alkaline batteries)
* Theodolite only : about 230 hours
* Laser only : about 80 hours (L Models)
* Theodolite and laser about 55 hours (L Models)
Laser-pointer (L Models)
* Signal source : Red laser diode (633nm)
* Maximum output : 0.6mW
* Laser Class : Class 2
* Laser beam range : 50m (in daylight)
Hardware
* Ingress Protection : Dust and water resistance IP66 (JIS C 0920 : 2003)
* Operating temperature range : -20 to 50°C (-4 to 122°F)*2
* Storage temperature range : -30 to 60°C (-22 to 140°F) (no condensation)
* Size (with handle)
- 5" and 7" Models: 173 (W) X 181 (D) X 318 (H) mm
- 9" Models: 173 (W) X 174 (D) X 318 (H) mm
* Weight (with batteries and battery holder)
- 5" and 7" Models: 4.1 kg (9.04 lb)
- 9" Models: 4.0 kg (8.82 lb)
Paket Penjualan TOpcon DT-309/309G
- 1 x Alumunium Tripod
- 1 x Rambu Ukur
Lightweight, compact angular measurement with highprecision laser guidance and up to 30 workdays of power
• Long-lasting Li-ion or AA battery life with up to 30 workdays*2
of power
• Convenient high-precision laser guidance
• Brand new product design utilizing Topcon premium quality
total station components
• Embedded tilt sensor in 5” model
• Ultra-rugged IP66 dust and heavy rain protection
The DT-300 is a lightweight compact alignment and angular measurement device which uniquely boasts up to 30 working days of power, the highest waterproof and dust protection, and convenient high precision laser guidance.
Features include
High-accuracy (5”, 7” and 9” models) measurements
Ultra-rugged IP66 dust and heavy rain protection
Compact and light weight
Long-lasting Li-ion or AA battery life
Easy-to-use LCD backlit display
Precise laser pointer guidance
Embedded tilt sensor for 5” and 7” models
Speksifikasi Digital Theodolite Topcon DT-309/309G
Telescope
* Length :
- 149mm
- 152mm (L models)
* Aperture : 45mm
* Magnification : 30X
* Image : Erect
* Field of view : 1°30’ (26m/1,000m )
* Resolving power : 2.5"
* Minimum focus
- 0.9m
- 1.0m(L)
* Stadia ratio : 100
* Stadia constant : 0
Angle measurement
* Method : Rotary absolute encoder
* Detecting :
- Horizontal: 1 sides
- Vertical: 1 sides
* Minimum Reading
- 5" Model: 1" (0.0002 gon/0.01 mil)/5" (0.001 gon/0.1mil) (selectable)
- 7" Model: 5" (0.002 gon/0.05 mil)/10" (0.005 gon/0.1mil) (selectable)
- 9" Model: 10" (0.002 gon/0.05 mil)/20" (0.005 gon/0.1mil) (selectable)
Display
* Unit
- 2 sides for 5” and 7” model
- 1 side for 9” model
Tilt angle compensation (5” and 7”models)
* Type : Automatic vertical compensator
* Range of compensation : ±3' (±0.0555 gon)
* Compensation constant : Can be changed (compensation is done at the same time with vertical angle 0 point)
Optical plummet
* Magnification : 3X
* Minimum focus : 0.5 m
Sensitivity of levels
* Circular level : 10’ /2mm
* Plate level : 30"/ 2mm
Power Supply
* Power source : 4 AA dry cells or BDC71 (Optional accessory)
Operating Time (4 AA alkaline batteries)
* Theodolite only : about 230 hours
* Laser only : about 80 hours (L Models)
* Theodolite and laser about 55 hours (L Models)
Laser-pointer (L Models)
* Signal source : Red laser diode (633nm)
* Maximum output : 0.6mW
* Laser Class : Class 2
* Laser beam range : 50m (in daylight)
Hardware
* Ingress Protection : Dust and water resistance IP66 (JIS C 0920 : 2003)
* Operating temperature range : -20 to 50°C (-4 to 122°F)*2
* Storage temperature range : -30 to 60°C (-22 to 140°F) (no condensation)
* Size (with handle)
- 5" and 7" Models: 173 (W) X 181 (D) X 318 (H) mm
- 9" Models: 173 (W) X 174 (D) X 318 (H) mm
* Weight (with batteries and battery holder)
- 5" and 7" Models: 4.1 kg (9.04 lb)
- 9" Models: 4.0 kg (8.82 lb)
Paket Penjualan TOpcon DT-309/309G
- 1 x Alumunium Tripod
- 1 x Rambu Ukur
